Detail

Model No. GV-152-H-BV
FEATURES
Maximum working pressure:
1000 psi (690 bar) at 30°C
Working temperature:
From 54°C to 450°C with PEEK Packing.
A 316 stainless steel handle covered with vinyl sleeve gives quarter turn rust-free operation.
Valves with PEEK seats are supplied with sleeves on handles. A robust pin is to create a positive stop.
The stem +with shoulder provides blowout proof design to maintain seal integrity at all pressure.
Optional sour gas service conforms to NACE Mr0175.
Ball valves are hydrostatic tested at the full rated pressure and low pressure pneumatic at 70 psi.
100% factory test
